1. Open single-track structure, easy to dock with automated lines and transfer stations at both ends, with reserved space for inspection and maintenance.
2. Cantilever X-axis design. The feeder follows the X-axis, so a screw pick-up only requires Z-axis travel, greatly reducing the movement time.
3. Equipped with a servo electric screwdriver and a spot-positioning camera. Torque is configurable and point alignment is easier.
4. The in-line section is divided into three stations: waiting zone, fastening zone and buffer zone, each with front and rear signal interfaces for line integration.
| Item | Specification |
| Workpiece size | Max. 320 x 500 mm |
| Width adjustment | 150-330 mm, automatic |
| Screw size | M1.0 - M3.0 |
| Cycle time | 1.5-2.5 s per screw |
| Conveying method | Belt conveyor with pneumatic positioning |
Online adsorption screw machine with single-track, single-head design. Docks with automated production lines through front and rear signal interfaces and is purpose-built for short, small screws that cannot be blown or blow-fed. Model HRD-BL14/X; workpiece up to 320 x 500 mm, width adjustable 150-330 mm, screw range M1.0 to M3.0, cycle time 1.5-2.5 s per screw.
