1、Features

lDownward folding structure with an air circuit cushioning design; the folding descent is smooth and controllable, allowing for quick folding to save workshop space, suitable for aisle connection scenarios, and can be folded and stored when not in use without occupying production line aisle space.

l Lightweight foldable support, equipped with folding hinges and support arms, locks when unfolded, and folds conveniently.

l Automatic width adjustment, variable speed control.

l Optional with dust cover or without dust cover.

l After a person presses the fold button, it folds. After passing through, the original state can be restored by pressing the fold button on the other side, using manual control.

2、Technical Specifications

Parameter Name	Parameter Value (Reference)
Applicable PCB Size	150×150mm ~ 340×270mm
PCB thickness	0.5mm ~ 5.0mm
Conveying speed	0.5-9m/minAdjustable
Transmission height	900 ± 20mm
Transmission Direction	Left → Right
Automatic width adjustment	150-300mm
Belt width	4mm，ESDAnti-static belt
Power consumption	AC 220V ±10V，50/60Hz，About150W
Air source and air consumption	0.6MPa，No air is consumed during normal use, air is consumed when folding the cylinder. Air pipe is 6mm.
Overall dimensions (for reference）	about L1200mm【After unfolding】W1000mmH1200mm
Overall machine weight	about95kg

Folding docking station

1. Functional features: downward-folding structure with pneumatic buffering for stable, controllable folding and lowering; enables rapid folding to save workshop space; suitable for aisle transfer scenarios; can be folded and stored when not in use without occupying production line aisle space. Lightweight folding support with folding hinges and support arms; locks once unfolded for easy folding. Automatic width adjustment and variable speed control. Optional with or without dust cover. Manual folding.
