Parameters: Screw and magnet import method - Adhesive type. Number of axes: 6 axes (double head, double workstation). Repeated positioning accuracy: ±0.02mm. Simultaneous locking of electric tools: 1 set (servo electric tool). Simultaneous number of magnets: 1 magnet. Loading method: Vibrating table + split pin. Effective travel (X1, X2, Y1, Y2, Z1, Z2): 850/850/1200/1200/100/100mm. Overall dimensions (length × width × height): 1300 × 1600 × 1750mm. Maximum product specification: L500 × W320mm (customizable). Weight: approximately 550kg. Control method: Motion control card +
Hotline: 0755-23170120
Parameters:
Screw and magnet introduction method | Adsorptive |
Number of axles | 6-axis (dual-head dual-station) |
Repeatability accuracy | ±0.02mm |
Simultaneously lock the number of electric screwdrivers | 1 unit (servo electric screwdriver) |
Number of magnets installed at the same time | 1 piece |
Magnet loading method | Vibrating plate nail separating |
Valid itinerary（X1.X2.Y1.Y2.Z1.Z2） | 850/850/1200/1200/100/100mm |
Dimensions (L × W × H) | 1300×1600×1750mm |
Maximum product specifications | L500×W320mm(Customizable) |
weight | about550kg |
Control method | Motion Control Card Joystick |
Power supply | AC220V，50Hz |
Working air pressure | 0.55-0.65MPa |
Function Introduction：
The jig uses a large adjustable jig mode, with precise positioning, compatible with multiple product specifications, improving production efficiency.
It has an automatic alarm function. When the screw experiences 'stripping' or 'feeding abnormality,' the machine automatically pauses and displays the alarm information on the handle.
Program storage: expanded to 1000 entries;
The electric screwdriver is a servo electric screwdriver, which can be set with multiple speed levels and multiple torque levels, improving fastening efficiency and enhancing fastening performance.
Equipped with a vibrating disc screw feeder and an upgraded magnetic feeder.
The front Z-axis has been locking the magnet sleeves, and the products with locked magnet sleeves will move to the back. The back Z-axis keeps installing magnets. This way, the dual-station interacts and locks efficiently and stably.
Both Z axes are equipped with camera-assisted point alignment, making positioning fast and efficient.
