Visual inspection, CCD inspection, concentricity inspection, concentricity visual inspection, height difference inspection
Hotline: 0755-23170120
1. Fully automatic visual inspection of concentricity and inner/outer plug height difference.
2. Inspection standards are configurable; concentricity accuracy ±0.01mm, height difference accuracy ±0.005mm. Higher accuracy available upon customization.
3. Multi-level authorization: workers only load/unload products and start the machine. In case of a defect, a higher-level authorization with password input is required to remove the defective product, preventing defective products from escaping.
4. Interfaces with MES system, features barcode scanning, and saves inspection standards and parameters to disk.
| Technical Specifications | Parameters |
| Concentricity Accuracy | ±0.01mm |
| Height Difference Accuracy | ±0.005mm |
| Moving Speed | XY=800mm/S, Z=300mm/s |
| Applicable Product Size | 300×300mm (customizable) |
